Extensometer
Extensometers are used for measuring a deflection directly on the test specimen. Extensometers comes in many different ways, from measuring very small deflections on reinforcing steel to large deflections on plastic materials.
| Epsilontech 3542-100M-010-ST | Epsilontech 3542-50M-010-ST | Long travel extensometer 1100 mm | Transducer for inner pipe diameter change | |
| Interfaces | Analog | Analog | Digital | Digital |
| Sensor excitation | 5 V | 5 V | ||
| Resolution | 0.04 mm | 0.04 mm | ||
| Operating temperature range | -40 deg C to 100 deg C | |||
| Options | Special coating and stainless steel knife edges available | Special coating and stainless steel knife edges available | ||
Epsilontech 3542-100M-010-ST:
Epsilontech 3542-100M-010-ST extensometer with shunt calibration.
Gauge length 100 mm – strain 10%.
Options:
- Quick attach kit wire forms for large specimens
- Adapter kits to change gauge lengths
- Connectors to interface to nearly any brand test equipment
- Special coating and stainless steel knife edges available
Product range of extensometers:
- Extensometers with different resolution levels, measuring principles, and measurement travel.
- Contact/non-contact measurement of extension, change in width, or strain.
| Interfaces | Analog | |||
| Sensor excitation | 5 V | |||
| Operating temperature range | -40 deg C to 100 deg C | |||
| Options | Special coating and stainless steel knife edges available | |||
Epsilontech 3542-50M-010-ST:
Epsilontech 3542-50-010-ST extensometer with shunt calibration. Gauge length 50 mm – strain 10%
Options:
- Quick attach kit wire forms for large specimens
- Adapter kits to change gauge lengths
- Connectors to interface to nearly any brand test equipment
- Special coating and stainless steel knife edges available
Product range of extensometers:
- Extensometers with different resolution levels, measuring principles and measurement travel.
- Contact/non-contact measurement of extension, change in width or strain.
Specifications
| Interfaces | Analog | |||
| Sensor excitation | 5 V | |||
| Operating temperature range | -40 deg C to 100 deg C | |||
| Options | Special coating and stainless steel knife edges available | |||
Long travel extensometer 1100 mm:
Long travel extensometer 1100 mm.
Specifications
| Interfaces | Digital | |||
| Resolution | 0.04 mm | |||
| Operating temperature range | -40 deg C to 100 deg C | |||
Transducer for inner pipe diameter change:
Transducer for inner pipe diameter change is mounted inside a pipe and measures the change of the inner diameter, when the pipe is compressed. The measuring range is from 150mm to 2000mm.
Specifications
| Interfaces | Digital | |||
| Resolution | 0.04 mm | |||
| Operating temperature range | -40 deg C to 100 deg C | |||
